GR5405 Starter Kit (GR5405 SK) is a Goodix proprietary platform that helps users quickly get started with project evaluation, development, debugging, and performance verification for GR5405 SoCs. The SK Board is designed to support a range of peripherals including external buttons, external Flash, LEDs, CAN, 2*LIN, and I/Os. It can be powered via USB cable, 12V battery, or external power sources.
GR5405 SK reserves an interface for power consumption testing, as well as an SMA interface for evaluating the RF performance of GR5405 SoCs.
For efficient project evaluation, development, and mass production, GR5405 SK users can also choose various development resources including GR5405 SDK for software development, GProgrammer for PC-based download and programming, GRToolbox for mobile debugging, GRUart and GRDirect Test Mode Tool for PC-based serial port debugging, GRPLT for mass production and configurations, and PLT for programming in mass production.
Bluetooth LE 5.3
J-Link/UART debugging
Configurations on I/O voltages
Power consumption test interface
Multi-functional buttons and LEDs
Conducted RF performance test connector
USB Type-C connector
CAN
2*LIN
On-board 16 MB Flash
On-board 3-bit node ID hardware configuration
| Name | Rights Description | Version | Date |
|---|---|---|---|
| GProgrammer User Manual | For Public | Rev.3.2 | 2024-09-20 |
| GR5405 Developer Guide | For Public | Rev.1.0 | 2024-09-20 |
| GR5405-SK-BASIC-RevC | For Public | Rev.1.0 | 2024-09-20 |
| GR5xx Power Consumption Profile Example Application | For Public | Rev.3.1 | 2023-11-28 |
| GR5xx FreeRTOS Example Application | For Public | Rev.3.1 | 2023-11-28 |
