Goodix is the inventor and market leader of optical IN-DISPLAY FINGERPRINT SENSOR™. By transforming a defined area of a display into a fingerprint "button" for various smart devices with AMOLED screens, the solution leads the evolution of bezel-less design. Goodix owned self-developed core technologies, ranging from IC design, software & algorithms, manufacturing & processing to testing solutions, which enables it to provide global customers with turnkey hardware and software solutions featuring both high performance and high quality.
Based on an optical collimator, fingerprint module as thin as 0.26 mm
Can be assembled on the middle frame by overlapping with the battery, no need to attach to the screen
Enables extra internal space for a larger capacity battery and improves the linear motor performance for a mobile phone
Allows for more flexible and more ergonomic designs of unlocking area
Goodix invented, extensively used in flagship models of renowned mobile phone brands
Applies the micro-focus technology based on the pinhole effect, fingerprint module as thin as only 3.2 mm to 4.2 mm
Matching latency as fast as only 75 ms
Can be assembled on the middle frame and placed side by side with the battery
Goodix invented, widely used in smart devices such as mid- and high-end mobile phones and tablets
| Part Number | Status | Applications | Product Type | FOV | Module Size | Supply Voltage | Interface |
|---|---|---|---|---|---|---|---|
| GW9558 | Active | Under AMOLED Display | Optical Lens Type | 6.5 mm * 6 .5 mm | 7.25 mm * 4.8 mm * 4.2 mm | 3.1~3.6 V | SPI |
| GW9578 | Active | Under AMOLED Display | Optical Lens Type | 6.5 mm * 6.5 mm | 5.84 mm * 4.63 mm * 4.2 mm | 3.1~3.6 V | SPI |
| GW9588 | Active | Under AMOLED Display | Optical Lens Type | 5.5 mm * 5.5 mm ~ 6.5 mm * 6.5 mm | 5.84 mm * 4.63 mm * 3.2 mm ~ 5.84 mm * 4.63 mm * 3.9 mm | 2.7~3.6 V | SPI |
| GW9628 | Active | Under AMOLED Display | Optical Ultra-thin | 6 mm * 6 mm | 14.3 mm * 12.84 mm * 0.28 mm | 2.6~3.6 V | SPI |
| GW9668 | Active | Under AMOLED Display | Optical Ultra-thin | 5 mm * 5 mm | 14.3 mm * 12.84 mm * 0.28 mm | 2.6~3.6 V | SPI |
Inventor and market leader of IN-DISPLAY FINGERPRINT SENSOR™
Winner of Edison Awards 2020
Strong optical and IC design capabilities with proprietary software and algorithms
1,500 patents applied or authorized worldwide
Applied in over 260 models of smartphones
Applicable to smart devices including mobile phones and tablets
Manufactured by the world's top IC foundries
Packaged and tested by our world's top partners
